512EVO Battery Charger / Maintainer

Item Number: XTQEZ0179B Supplier: E-XTEQ LLC

Description

512EVO Automatic 12V/50A charger/maintainer and quick diagnostic for 12V lead, AGM, EFB, Li-Ion batteries. Uses include pre-delivery inspection, showroom, used car inspection, and power supply for ECU reloading of battery exchange.

Feature and Benefits

Fully automatic
- No user action is required other than connecting the device to the power supply and the clamps to the battery.
Robust and flexible, all in one
- The BC512 may be used in all areas of the garage and aftersales workshop. It charges and performs diagnostics for 12V batteries.
Simple to use
- An intuitive, text-free graphics interface, displays all the results to the user. The 512EVO can therefore be used without any specific training or skills.
Safe
- The BC512 has several safety devices, including reverse polarity protection.

Includes

512EVO Charger and Quick Start
5M Power Cord to IEC C13
Cable for update / Connection to a diagnostic tool
Charge Cable, 2m, with ergonomic clamps

Attributes

User interface:
- Backlit monochrome display (128 x 64 px)
- Status LED for charge, battery ok, alarm Icons based with non text messages buzzer
Housing:
- Aluminum body with metal handle
- Anti slip, shock proof rubber sides
- Magnets to hang the device
- Security sling
Output:
- 15.1 V for normal charge & 13.5 V for floating mode (automatic switching) and power supply
- Limited current: 50 A
- Ripple voltage: 150 mV p-p
- Easy plug connector

Input:
- 90 – 264 VAC 47/63 Hz (for worldwide networks)
- Less than 10 A (115 V) / 5 A (230 V)
- Simple connection with CEI22 cable (same as computer)
- Power factor 97%
- P.F.C (Power factor corrector)

Warranty

One year

Product Specifications

Connectivity: SUBD9: diagnostic tool connection, software updates
Dimensions: 13.5" x 11" x 5"
Humidity: 20 to 80 % non condensing
Limited Current: 50 A
Noise Level: 65 dB at 50A
Temperature (Stock): -30 to +60°C
Temperature (Usage): -15 to +40°C
Weight: 14 lbs.
